An embedded industrial display, with a flat front panel that is thin and compact, and featuring IP65 level dustproof and waterproof packaging, is the preferred model for embedded installation of cabinet-type equipment. It supports 7'' - 23.8'' capacitive/resistive touch screens and non-touch options, as well as VGA + HDMI + DP signal interfaces. The aluminum die-cast shell enhances the mechanical rigidity, anti-interference and heat dissipation performance of the entire machine, and is not affected by harsh conditions such as high and low temperatures, oil stains, dust, and vibrations. It is an ideal choice for industrial control, terminal integration, and human-computer interaction.
 |  |
Covering security display and control screens, medical displays, and commercial displays, we provide customized industrial LCD system solutions
| Color :16.7M | Pixel pitch:0.297(H) X 0.297(V) |
| Screen panel :Industrial control screen | Contrast ratio :700:1 |
| Display brightness :300cd/㎡ | Gray-scale response time :6.5ms |
| Working temperature :-10 °C to 60 °C | Power consumption :20W |
| Power input :AC 100-240V, 50/60Hz | Storage temperature :-20 °C to 70 °C |
| Power output :DC 24V / 1.5A | Relative humidity :20% - 95% |
| Backlight type : LED backlight screen, with a lifespan of ≥50,000 hours | |
| Viewing angle : 80/80/70/70 (L/R/U/D) full viewing angle | |
| Touching method : Three options available - non-touch, capacitive touch, and resistive touch | |
| Installation method : Embedded, wall-mounted, desktop, wall-mounted, and louvre horizontal installation | |
